Functional description
170 MPR-e
The source and destination MAC addresses can also be summarized by the following formula
linked to the slot and port number in HEX:
PMC card source MAC address: 00-80-9F-09-F<slot#>-<port#><slot#>
PMC card destination MAC address: 00-80-9F-09-F<slot#>-0<slot#>
For example, for slot number 4 and port number 2:
Source MAC address = 00-80-9F-09-F4-24
Destination MAC address = 00-80-9F-09-F4-04
Synchronization: 7705 SAR and MPR-e Single NE
In a Single NE solution no special configuration is required. Both 7705 SAR and MPR-e self-
detect the port selected and consequently configure the correct synchronization method.
When copper interface is used either using native RJ-45 or Copper SFP on the PMC
(7705 SAR) side, PCR is selected both by MPR-e and 7705 SAR self-assigning right MAC
addresses.
When optical interface is used, SynchE is selected by both MPR-e and 7705 SAR.
12 1 00-80-9F-09-FC-1C 00-80-9F-09-FC-0C
2 00-80-9F-09-FC-2C
3 00-80-9F-09-FC-3C
4 00-80-9F-09-FC-4C
Table 75: 7705 SAR PMC card MAC addresses
SAR slot
#
PMC port # Source MAC address Destination MAC address
Note: Slot 7 TO 12 are applicable to SAR-18 chassis only.
