WebEML start
176 MPR-e
Figure 66: Main view: system overview
8. Figure 67 shows the banner that is displayed for the craft user. The Administration
tab and Administrative functions are not available for the craft user.
Figure 67: Craft user banner
Alarm
Synthesis
Tab panels User Account
type
IP address
of the
connected NE
General
information
Navigator
Tool bar
Domain alarm
synthesis
23701
Note: If the WebEML is connected to an MPT-HC V2/MPT-XP/9558HC with the XPIC +
RPS external module installed (but with no XPIC feature configured), the screen in
Figure 68 will appear.
