Alcatel-Lucent 9558HC - 13 To 38 Ghz; Table 15 MPT-HC V2 Characteristics, 13 to 38 Ghz (MPR-E)

Product information and planning
MPR-e 91
13 to 38 GHz
Typical power consumption
(MPT-HC V2 with RPS
module)
5.8 to 10.5, 38 GHz: 38.5 W
11 to 25 GHz: 37 W
Guaranteed power
consumption (MPT-HC V2
with RPS module)
40 W
Typical power consumption
(MPT-HC V2 with XPIC-
RPS module)
5.8 to 10.5, 38 GHz: 45.5 W
11 to 25 GHz: 44 W
Guaranteed power
consumption (MPT-HC V2
with XPIC-RPS module)
48 W
Table 14: MPT-HC V2 characteristics, 5.8 to 11 GHz (MPR-E)
5.8 GHz L6 GHz U6 GHz 7 GHz 8 GHz 10.5
GHz
11 GHz
Table 15: MPT-HC V2 characteristics, 13 to 38 GHz (MPR-E)
13 GHz 15 GHz 18 GHz 23 GHz 25 GHz 38 GHz
System
Frequency Range, GHz 12.75 -
13.25
14.4 -
15.35
17.7 -
19.7
21.2 -
23.632
24.52 -
26.483
37.0 -
39.46
T-R Spacings supported, MHz 266 308;
315;
322;
420;
490;
640;
644;
728
1008;
1010;
1560;
340
1008;
1050;
1200;
1232
1008 1260
Antenna Interface
Waveguide Type WR62 WR62 WR42 WR42 WR42 WR28
