100 Rockwell Automation Publication 750-IN001P-EN-P - April 2017
Chapter 3 Lift and Mount the Drive
Figure 64 - IP54, NEMA 12, MCC Style Cabinet, Floor Mount Frame 8 Bottom Access
(Enclosure Codes K and Y)
IP54, UL Type 12, MCC Style Cabinet, Floor Mount Frame 8 Bottom Access
(Enclosure Code J) with P14
270
(10.6)
270
(10.6)
127
(5.0)
1
2
2
1
76
(3.0)
ø18.0
(0.71)
742
(29.2)
43
(1.7)
300
(11.8)
531
(20.9)
669
(26.3)
900
(35.4)
1131
(44.5)
69
(2.7)
200
(7.9)
440
(17.3)
440
(17.3)
800 mm (31.5 in.) Deep Drive with Wiring Bay
No. Description
1 Power wiring conduit plates.
2 Control wiring conduit plates.
