104 Rockwell Automation Publication 750-IN001P-EN-P - April 2017
Chapter 3 Lift and Mount the Drive
Figure 68 - IP20, NEMA/UL Type 1, MCC Style Cabinet, Floor Mount Frame 9 Bottom Access
(Enclosure Code B with P14)
ø18.0
(0.71)
542
(21.3)
43
(1.7)
300
(11.8)
531
(20.9)
669
(26.3)
900
(35.4)
1131
(44.5)
69
(2.7)
1269
(50.0)
1500
(59.1)
1731
(68.1)
500
(19.7)
500
(19.7)
440
(17.3)
141
(5.6)
1
1
1
2
2
127
(5.0)
76
(3.0)
76
(3.0)
205
(8.1)
600 mm (23.6 in.) Deep Drive with Cabinet Options Bay
No. Description
1 Power wiring conduit plates.
2 Control wiring conduit plates.
