116 Rockwell Automation Publication 750-IN001P-EN-P - April 2017
Chapter 3 Lift and Mount the Drive
Figure 80 - IP54, NEMA 12, MCC Style Cabinet, Floor Mount Frame 9 Bottom Access
(Enclosure Codes K and Y)
IP54, UL Type 12, MCC Style Cabinet, Floor Mount Frame 9 Bottom Access
(Enclosure Code J)
76
(3.0)
440
(17.3)
76
(3.0)
440
(17.3)
270
(10.6)
1
1
1
2
2
2
127
(5.0)
440
(17.3)
ø18.0
(0.71)
742
(29.2)
43
(1.7)
300
(11.8)
531
(20.9)
669
(26.3)
900
(35.4)
1131
(44.5)
69
(2.7)
1269
(50.0)
1500
(59.1)
1731
(68.1)
76
(3.0)
800 mm (31.5 in.) Deep Drive with
Cabinet Options Bay
No. Description
1 Power wiring conduit plates.
2 Control wiring conduit plates.
