Rockwell Automation Publication 750-IN001P-EN-P - April 2017 27
Prepare for Installation Chapter 2
Table 5 - PowerFlex 750-Series 600V/690V Input Drives RF Emission Compliance and
Installation Requirements
Standard and Limits
Drive Frame
Catalog Number
EN 61800-3 Category C1
EN 61000-6-3
CISPR11 Group 1 Class B
EN 61800-3 Category C2
EN 61000-6-4
CISPR11 Group 1 Class A
(Input Power ≤ 20 kVA)
EN 61800-3 Category C3
(I ≤ 100 A)
CISPR11 Group 1 Class A
(Input Power > 20 kVA)
EN 61800-3 Category C3
I > 100 A
Wall Mount Frame 3: 600V (3 Hp
and higher.)
20F11xE3P9…20F11xE022
20G11xE3P9…20G11xE022
50 m (164 ft) cable limit with
Schaffner FN258HV-42-33 filter.
Supplementary EMC enclosure is
required to provide attenuation of
radiated emissions.
30 m (98.4 ft) motor cable limit with
one input and one output core.
(1)
30 m (98.4 ft) motor cable limit with
one input and one output core.
(1)
N/A
Wall Mount Frame 4: 600V
20F11xE027…20F11xE032
20G11xE027…20G11xE032
50 m (164 ft) cable limit with
Schaffner FN258HV-55-34 filter.
Supplementary EMC enclosure is
required to provide attenuation of
radiated emissions.
30 m (98.4 ft) motor cable limit with
one input and one output core.
(1)
30 m (98.4 ft) motor cable limit with
one input and one output core.
(1)
N/A
Wall Mount Frame 5: 600V
20F11xE041…20F11xE052
20G11xE041…20G11xE052
50 m (164 ft) cable limit with
Schaffner FN258HV-100-35 filter.
Supplementary EMC enclosure is
required to provide attenuation of
radiated emissions.
30 m (98.4 ft) motor cable limit with
one input and one output core.
(1)
30 m (98.4 ft) motor cable limit with
one input and one output core.
(1)
N/A
Wall Mount Frame 6: 600V/690V
20F11xx012…20F11xx144
20G11xx012…20G11xx144
50 m (164 ft) cable limit with
Schaffner FN258HV-100-35 filter (up
to 90 kW drives) or FN3359HV-250-28
filter (110 kW and larger drives).
Supplementary EMC enclosure is
required to provide attenuation of
radiated emissions.
50 m (164 ft) cable limit with
Schaffner FN258HV-100-35 filter (up
to 90 kW drives) or FN3359HV-250-28
filter (110 kW and larger drives).
Supplementary EMC enclosure is
required to provide attenuation of
radiated emissions.
30 m (98.4 ft) motor cable limit with
one input and one output core.
(1)
30 m (98.4 ft) motor cable limit with
one input and one output core.
(1)
Frame 7: 600V/690V
20F11xx192…20F11xx289
20G11xx192…20G11xx289
50 m (164 ft) cable limit with
Schaffner FN3359HV-400-99 filter.
Supplementary EMC enclosure is
required to provide attenuation of
radiated emissions.
50 m (164 ft) cable limit with
Schaffner FN3359HV-400-99 filter.
Supplementary EMC enclosure is
required to provide attenuation of
radiated emissions.
30 m (98.4 ft) motor cable limit with
one input and one output core.
(1)
30 m (98.4 ft) motor cable limit with
one input and one output core.
(1)
More Stringent Limits Less Stringent Limits
(1) Rating-specific EMC cores are part of EMC kit numbers 20-750-EMC3-nn and 20-750-EMC4-nn.
