Allen-Bradley 20F Installation Instructions

Rockwell Automation Publication 750-IN001P-EN-P - April 2017 89
Lift and Mount the Drive Chapter 3
Figure 53 - IP20, NEMA/UL Type 1, MCC Style Cabinet, Floor Mount Frame 8
(Enclosure Code B)
M12 (1/2 in.) Property Class 8.8 anchor hardware is recommended
to fasten the drive cabinet through its internal mounting angle to the
foundation. Anchor bolts can be pre-located and embedded in the
foundation before instillation.
2453
(96.6)
1200
(47.2)
2300
(90.6)
68
(2.7)
76
(3.0)
1
1
1
1
2
2
3
4
5
180
(7.1)
127
(5.0)
300
(11.8)
531
(20.9)
669
(26.3)
900
(35.4)
1131
(44.5)
69
(2.7)
ø18.0
(0.71)
542
(21.3)
43
(1.7)
600
(23.6)
240
(9.4)
1808
(71.2)
500
(19.7)
440
(17.3)
205
(8.1)
141
(5.6)
127
(5.0)
76
(3.0)
440
(17.3)
440
(17.3)
1464
(57.6)
No. Description
1 Power wiring conduit plates.
2 Control wiring conduit plates.
3 Optional exhaust hood.
4Optional HIM.
5 Recommended four-hole anchoring.
Bottom
Top
Bottom
600 mm (23.6 in.) Deep Drive with Cabinet Options Bay
