174 Rockwell Automation Publication 1789-UM002K-EN-P - January 2015

Appendix A Communicate with Devices on a DeviceNet Network

4. Click OK.

An upload/download prompt dialog box appears.

5. Click OK.

IMPORTANT

If you cannot browse the network after installing the 1784-PCIDS card,

check and make sure the status indicator on the card is green. If it is

red, see the DeviceNet Universal PCI Scanner Card Installation

Instructions, publication 1784-IN004

, for detailed troubleshooting

information about status indicators.
