9-13
AP AMP ASE [Application (Pout Pase)]
Function
During the measurement made using a polarization nullification method, copies
the spectrum temporarily written into the Pout memory to the internal memory
Pase as an ASE.
Setting is enabled only in the optical AMP measurement mode.
Header Program Query Response
AP AP AMP, ASE
AP WDM [Application (WDM)]
Function
Sets to WDM Application
The display mode at this time uses the previously backed-up value.
Header Program Query Response
AP AP WDM
AP WDM, SLV, n
AP WDM, MPK
AP WDM, SNR, d, ∆ λ, s
AP WDM, REL, r
AP WDM, TBL, d, ∆ λ, s
AP? WDM
AP? WDM, SLV
AP? WDM, MPK
AP? WEM, SNR
AP? WDM, REL
AP? WDM, TBL
WDM, m
WEM, SLV, n
WDM, MPK
WDM, SNE, d, ∆ λ, s
WDM, REL, r
WDM, TBL, d, ∆ λ, s
Send Data
Value of n
Sets splice level at splice level setting command (SLV)
n = 1 to 50 [dB]
Value of d
Sets noise detection direction at SNR display
d = LEFT: Left side
= RIGHT: Right side
= HIGHER: Side with highest level
= AVERAGE: Average of LEFT and RIGHT
Value of λ
Setting for detection position using wavelength difference at SNR display.
Evaluates SNR of point at ∆λ from peak in direction specified at s.
∆λ = 0 [nm] or OFF : Auto-detects Dip in specified direction
∆λ = 0 to +20 [nm] (0.01 step)
