Section 9 Details on Device Messages
9-14
• Value of r
Sets reference peak to r number at REL (Relative) display
r = 1 to 128
• Value of s
Sets whether the detected noise value should be normalized with the effective
resolution.
s = "ON"
= "OFF"
■ Response Data
m indicates the display mode as follows:
m = MPK: Multi Peak display
= SNR: SNR display
= REL: Relative display
Refer to the send data items for n, s, ∆λ, and r.
AP WDM, PKT, t [Application WDM Peak Type]
■ Function
Sets the method for detecting the signal wavelength in the WDM application.
Header Program Query Response
AP AP WDM, PKT, t AP ? WDM, PKT WDM, PKT, t
■ Parameters
• Value of t
Selects a method for detecting the signal wavelength in the WDM application.
MAX ................ The wavelength at the maximum point shall be the signal
wavelength.
THRESHOLD .. The Threshold analysis central wavelength shall be the sig-
nal wavelength.
■ Initial setting value
t is a backed up value.
■ Default
t = MAX
