11-15
MS9710A Analysis ;SMSR
MS9710
SMSR
This driver performs SMSR analysis and outputs the analysis result.
Input parameter:
Side Mode (no change)............... Outputs the center wavelength.
If analysis is impossible, –1 is output.
Output parameters:
∆ λ (nm) or (THz)....................... Outputs the difference in wavelength between the main peak and the side mode.
If analysis is impossible, –1 is output.
∆ l (dB) ....................................... Outputs the difference in level between the main peak and the side mode. If
analysis is impossible, –999.99 is output.
MS9710A Analysis ;Spectrum Power
MS9710
Pow.
This driver carries out power integration and outputs the analysis result.
Output parameters:
Power (dBm) .............................. Outputs the power integration value.
λ c (nm) or (THz) ....................... Outputs the center wavelength.
MS9710A Analysis ;Threshold
MS9710
Thrshld
This driver carries out spectrum analysis using a threshold method and outputs the analysis result.
Input parameter:
Cut Level (dB) (no change) ........ CutLevel(dB) (no change): Set a cut level (1 to 50 dB).
If no value is input, the previous setting is used.
Output parameters:
λ c (nm) or (THz) ....................... Outputs the center wavelength. If analysis is impossible, –1 is output.
∆ λ (nm) or (THz)....................... Outputs the spectrum width. If analysis is impossible, –1 is output.
MS9710A Appli ;Application Off
MS9710
Off
This driver terminates application measurement.
11.4 Description of Measuring Instrument Driver Functions
