Section 11 LabVIEW Measuring Instrument
11-14
MS9710A Analysis ;Analysis Off
MS9710
Off
This driver cancels the analysis mode.
MS9710A Analysis ;Envelope
MS9710
Env.
This driver carries out spectrum analysis using the Envelope method and outputs the analysis result.
Input parameter:
Cut Level (dB) (no change) ........ Cut Level (dB) (no change): Set a cut level (1 to 20 dB).
If no value is input, the previous setting is used.
Output parameters:
λ c (nm) or (THz) ....................... Outputs the center wavelength. If analysis is impossible, –1 is output.
∆ λ (nm) or (THz)....................... Outputs the spectrum width. If analysis is impossible, –1 is output.
MS9710A Analysis ;ndB-Loss
MS9710
ndB
This driver carries out spectrum analysis using an ndB-Loss method and outputs the analysis result.
Input parameter:
Cut Level (dB) (no change) ........ Set a cut level (1 to 50 dB).
If no value is input, the previous setting is used.
Output parameters:
λ c (nm) or (THz) ....................... Outputs the center wavelength. If analysis is impossible, –1 is output.
∆ λ (nm) or (THz)....................... Outputs the spectrum width. If analysis is impossible, –1 is output.
N .............................................. Outputs the number of axis modes. If analysis is impossible, –1 is output.
MS9710A Analysis ;RMS
MS9710
RMS
This driver carries out spectrum analysis using an RMS method and outputs the analysis result.
Input parameters:
Sigma Factor:∆ λ (no change) ... ∆ λ (σ, 2σ, 2.35σ 3σ)
If no value is input, the previous setting is used.
S.Level (dB) (no change) ........... Set a slice level (1 to 30 dB).
If no value is input, the previous setting is used.
Output parameters:
λ c (nm) or (THz) ....................... Outputs the center wavelength. If analysis is impossible, –1 is output.
k σ (nm) or (THz) ....................... Outputs the spectrum width. If analysis is impossible, –1 is output.
