11-13
MS9710A Read Memory Data
MS9710
↓
Data
This driver outputs the measurement data (Data/Suffix) and data measurement conditions (Condition Data) from the
memory.
Input parameter:
Memory A/B (Memory A: F) ..... Select a memory from which data is to be read.
Output parameters:
Condition Data [cluster] ............. The following cluster elements are output:
1. Start Wavelength (nm) ......... Start wavelength
2. Stop Wavelength (nm) ......... Stop wavelength
3. Sampling Points ................... Number of sampling points
Data ............................................ Measurement data is output. The number of arrays is equal to the number of
sampling points.
Suffix (dBm, mW)...................... The unit of measurement data is output. When the log scale is selected, dBm is
output. When the linear scale is selected, mW is output.
MS9710A Sweep Start
MS9710
Single
Repeat
This driver starts single/repeat sweep.
In the single sweep mode, the VI is terminated after completion of sweep.
In the repeat sweep mode, the VI is terminated after completion of sweep averaging if Sweep Average is ON. If
Sweep Average is OFF, the VI is terminated after start of sweep.
Input parameters:
Single/Repeat (Single: F) ........... Select single or repeat sweep.
timeout (ms) (600000) ................ Set a single sweep timeout time.
MS9710A Sweep Stop
MS9710
Stop
This driver stops sweep.
MS9710A Trace Marker to Center
MS9710
TMrk
Center
This driver sets the trace marker wavelength to the center wavelength.
11.4 Description of Measuring Instrument Driver Functions
