Section 11 LabVIEW Measuring Instrument
11-20
MS9710A Appli ;Opt.Amp-Pout to ase
MS9710
Amp•ase
During the measurement made using a polarization nullification method (PlznNull), this driver copies the spectrum
temporarily written into the Pout memory to the internal memory Pase as an ASE.
MS9710A Appli ;Opt.Amp-Res.Cal
MS9710
Amp•Cal
During the optical AMP measurement, this driver calibrates resolution of the optical spectrum analyzer. After
completion of calibration, the VI is terminated.
Input parameters:
Mode Select (Initial: 0)............... Initial sets the resolution calibration data to the default value.
Execute starts calibration.
Timeout (ms) (600000) .............. Set a resolution calibration timeout time.
MS9710A Appli ;PMD Test
MS9710
PMD
This driver measures PMD (Polarization Mode Dispersion) and outputs the result. The measurement mode is set to
Auto.
Input parameter:
Mode Cpl Factor (no change) ..... Mode Cpl Factor (no change): Set Mode Cpl Factor (0.01 to 1.00).
When no value is input, the previous setting is used.
Output parameters:
Result [cluster] ........................... The following cluster elements are output:
If analysis is impossible, –1 is output.
1. Diff.Group Delay (fs) ........... Differential group delay time
2. 1st Peak Wavelength (nm) ... First peak wavelength
3. Last Peak Wavelength (nm) .. Last peak wavelength
4. Peak Count ........................... Number of peaks included in analysis range
