11-21
MS9710A Application ;WDM
MS9710
WDM
This driver sets parameters used in the WDM application.
Input parameters:
Display Mode (0. No Change) ... Sets display mode
0. No Change
1. Multi Peak ............................ Sets Multi Peak display
2. SNR ...................................... Sets SNR display
3. Relative ................................ Sets Relative display
4. Table..................................... Sets Table display
Level (dB) (No Change) ............. Sets slice level
Input Parameter (No Change)... Sets the following parameters. This is cluster.
SNR Dip Direction (No Change) .... Sets search direction in SNR Display
0. No Change
1. Higher
2. Left
3. Right
Delta Lambda (nm) (No Change) ... Sets D l in SNR Display
Reference Peak No. (No Change) ... Sets Ref Peak No. in Relative display
MS9710A Application ;WDM-R
MS9710
WDM-R
This reads the results of the WDM application.
Input parameter:
Sort Wl/Lvl (Wl) ........................ Whether the data are aligned in ascending order of wavelength or in descending
order of level.
Output parameters:
Peak Count ................................. Outputs number of peaks.
Gain Tilt. (dB) ............................ Outputs Gain Tilt in SNR Display. When analysis is impossible, –999.99 is output.
Result .......................................... Outputs analysis results. This is cluster in one order array.
Wavelength (mm) ....................... Outputs wavelength at peak level or –1 when analysis is impossible
Level (dB)................................... Outputs peak level or –999.99 when analysis is impossible
SNR (dB) .................................... Outputs SNR value in SNR Display or –999.99 when analysis is impossible
SNR Direction ............................ Outputs SNR detection direction in SNR Display or –999.99 when analysis is
impossible.
Spacing (mm) ............................. Outputs spacing in Relative Display or –999.99 when analysis is impossible
Relative Wl (nm) ........................ Outputs relative wavelength in Relative Display or –999.99 when analysis is
impossible.
Relative Lvl (dB) ........................ Outputs relative level in Relative Display or –999.99 when analysis is
impossible.
Frequency (THz) ........................ Output peak frequency.
Spacing F (GHz) ......................... Output spacing frequency.
11.4 Description of Measuring Instrument Driver Functions
