MS9710C Device Message List (11/13)
Item
Command
Data
request
Response
WOFS n
WCAL n
n = 0: W-CAL
INITIAL
1: W-CAL1
2: W-CAL2
3: Forced end
ALIN n
n = 0: ALIGN
INITIAL
1: ALIGN
2: Forced end
LOFS n
n= ±xx.x x
R CAL n
n = 0: INITIAL
= 1: EXCUTE
CSAV n
n = 1 to 5
CRCL n
n = 0 to 5
DATE yy, mm,
dd
TIME hh, mi
TDSP s
s = ON, OFF
LCD P, R, G, B
BKL n
n = 1 to 20, 0
BUZ s
s = ON, OFF
WOFS?
WCAL?
ALIN?
LOFS?
RCAL?
DATE?
TIME?
TDSP?
LCD?P
BKL?
BUZ?
n
n = ±xx.x
m
m = 0: Calibration
complete
1: During
calibration
2: Insufficient
optical level
3: Other faults
m
m = 0: Calibration
complete
1: During
processing
2: Insufficient
optical level
3: Other faults
n
n=±xx.x x
m
m = 0: Initial
1: Ended nomally
2: Excuting
3: Ended
abnormally
yy, mm, dd
hh, mi
s
s = ON, OFF
R, G, B
n
n = 1 to 20, 0
s
s = ON, OFF
Device message
Remarks
Calibra-
tion
Condi-
tion
Time &
Date
Set
Wl-Offset
Wl-
Calibration
Auto
Alignment
Lvl-Offset
Res Cal
Save
Recall
Date
Time
Time & Date
On/Off
Offset wavelength (nm)
W-CAL1;EXT.LIGHT
W-CAL2;REF.LIGHT
n: Offset value (dB)
–30 to +30
n: Save memory No.
n: Recall memory No.
0: Init
yy: 00 to 99
mm: 01 to 12
dd: 01 to 31
hh: 00 to 23
mi: 00 to 59
P: Screen No. (0 to 10)
RGB: 0 to 7
n: Time (min) until
light is turned off
9.94
9.92
9.1
9.48
9.66
9.17
9.16
9.18
9.83
9.81
9.46
9.12
9.13
Display Color
Auto Backlight
Buzzer
