9-1
Section 9 Mechanical Configuration
This section shows the mechanical configuration figures to disassembling/reassem-
bling the MT8801B for servicing.
Fig. 9-1 Top Disassembly
Fig. 9-2 Rear Disassembly
Fig. 9-3 Bottom Disassembly (1/2)
Fig. 9-4 Bottom Disassembly (2/2)
Fig. 9-5 LCD Disassembly (1/3)
Fig. 9-6 LCD Disassembly (2/3)
Fig. 9-7 LCD Disassembly (3/3)
Fig. 9-8 Chassis Disassembly
Fig. 9-9 A10 CONVERTER Disassembly (1/3)
Fig. 9-10 A10 CONVERTER Disassembly (2/3)
Fig. 9-11 A10 CONVERTER Disassembly (3/3)
Fig. 9-12 A13 SG1 Disassembly (1/3)
Fig. 9-13 A13 SG1 Disassembly (2/3)
Fig. 9-14 A13 SG1 Disassembly (3/3)
Fig. 9-15 A131 SG LOCAL Disassembly (1/2)
Fig. 9-16 A131 SG LOCAL Disassembly (2/2)
CAUTION
When disassembling/reassembling the MT8802A, turn off
the power switches on the front and rear panels, and discon-
nect the power supply cord for the ac outlet.
To Next Page
