10-1
Section 10 Exchange Module List
No PC Board/Module Name MS reference/Mfg. No.
1 322U13212 A01 MAIN CPU 34Y109569
2 322U13214 A02 BASE BAND1 34Y109570
3 322U13216 A03 BASE BAND2 34Y109571
4 MM00006A CDMA BASE BAND 34Y117989
5 MM00007A CDMA IQ 34Y117990
6 322U13220 A05 MOD DSP1 34Y109573
7 322U13616 A16 AF 34Y109606
8 MM00001A DEMOD DSP 34Y119123
9 MM00004A IF 34Y109590B
10 322U13232 A11 LOCAL 34Y109589
11 MM00008A DEMOD RF 34Y117991
12 MM00009A HPF UNIT 34Y118474
13 MM00003A CONVERTER 34Y118472
14 34Y113322 SG LOCAL UNIT 34Y113322
15 MM00005A SG1 34Y118473
16 34Y110740 A15 REFERENCE 34Y110740
17 SEC200-5222 Z3 POWER SUPPLY1 S4Z22106
18 HY122R1GN Z4 POWER SUPPLY2 No 1150
19 MM00002A RF INTERFACE 34Y118469
20 339H40998 HR S-ATT 339H40998
21 HPS-2H(10) POWER DIVIDER No 1305
22 LTM08C015KA Z5 LCD No 1251
23 INVC193 Z6 LD INVERTER No 1285
24 339H36932C HR S-ATT 339H36932C
25 FD-05HG-5701 Z8 FDD S4Z10498A
26 322U13222 A07 PANEL CONTROL 34Y109575
27 322U13646 A19 FREQ CONT 34Y109614
