9-18
Section 9 Mechanical Configuration
Fig. 9-16 A131 SG LOCAL Disassembly (2/2)
..
..
.
[51] 34B113336 Mounting Plate (Upper)
[15] MM00005A SG1
[52] 34B113337 Mounting Plate (Under)
[14] 34Y113322 SG LOCAL UNIT
