9-6
Section 9 Mechanical Configuration
[53] 34B11836 Mounting Plate
[54] 34B118366 Shielding Gasket 2
[55] 33B37677 Bracket
[56] 34B118641 Shielding Gasket 1
[25] FD-05HG-5701 Z8 FDD
Fig. 9-4 Bottom Disassembly (2/2)
