ARRI ALEXA Mini User Manual

Switching on/off 23
To check the recording status
The recording status is indicated as follows:
Record status LED (3) is... Camera is...
solid green ready for recording
solid red recording
off not ready for recording. Check, if
the CFast 2.0 card is valid. If not:
Insert a valid CFast 2.0 card. See
page 142.
flashing green/red alternately not ready for recording due to an er-
ror.
Check alert screen on MVF-1 for
reasons.
Reboot camera.
NOTICE
The recording status is also visible in the home screen, the live screen, the EVF
image, and the SDI image.

ARRI ALEXA Mini Specifications

General

Sensor Type	ALEV III CMOS
Dynamic Range	14+ stops
Recording Formats	ARRIRAW, ProRes
Power Input	10.5-34 V DC
Base Sensitivity	EI 800
Lens Mount	PL mount
Weight	2.3 kg
ISO Range	160 to 3200
Frame Rates	0.75 - 200 fps (depending on recording format and sensor mode)
Dimensions	185 mm x 125 mm x 140 mm
Power Consumption	Approx. 50 W
Outputs	HD-SDI
Sensor Size	Super 35 format
