ARRI ALEXA Mini User Manual

Home screen 87
13.8.3 Adding a LOOK file
NOTICE
You can add look files either from the camera default look folder or via a USB
memory stick.
Look files are copied from the USB to the camera. If you remove the memory stick,
the installed look files remain accessible.
2
3
1
1. Save all look files to be added on a properly prepared USB memory stick, in the
folder /ARRI/A-MINI/LOOKFILES.
2. Open the media lid (1).
3. Connect the USB memory (3) to the camera (2).
HOME > LOOK > SET LOOK

ARRI ALEXA Mini Specifications

General

Sensor Type	ALEV III CMOS
Dynamic Range	14+ stops
Recording Formats	ARRIRAW, ProRes
Power Input	10.5-34 V DC
Base Sensitivity	EI 800
Lens Mount	PL mount
Weight	2.3 kg
ISO Range	160 to 3200
Frame Rates	0.75 - 200 fps (depending on recording format and sensor mode)
Dimensions	185 mm x 125 mm x 140 mm
Power Consumption	Approx. 50 W
Outputs	HD-SDI
Sensor Size	Super 35 format
