ARRI ALEXA Mini User Manual

Web remote 55
12 Web remote
ALEXA Mini has a web remote function for full remote control of the camera with a
web browser (tested with: Google Chrome 39 and Mozilla Firefox 34). It requires a
connection to the camera via WiFi or Ethernet (with ALEXA Ethernet/RJ-45 Cable
KC-153-S, K2.72021.0).
By default, WiFi is active. If WiFi is inactive, enable WiFi via the MVF-1, by navigating
to MENU>System. Without the MVF-1, the webremote must first be used via a cabled
Ethernet connection to enable WiFi.
Open a web browser* and enter the URL: http://mini-xxxxx.local (replace xxxxx with
the 5-digit serial number of your camera).
NOTICE
To use the webremote function via this URL, the device must support zero-
configuration networking (zeroconf), e.g. through Apple Bonjour. Without zeroconf,
the webremote can be reached via the IP adress of the network (WiFi or LAN IP).
The WiFi IP is fixed to 192.168.153.1. The LAN IP is dynamic and can be checked
with an MVF-1 via the Network info screen.
MAIN, PLAY, REC INFO and USER
Web remote is divided into the following four sections:

ARRI ALEXA Mini Specifications

General

Sensor Type	ALEV III CMOS
Dynamic Range	14+ stops
Recording Formats	ARRIRAW, ProRes
Power Input	10.5-34 V DC
Base Sensitivity	EI 800
Lens Mount	PL mount
Weight	2.3 kg
ISO Range	160 to 3200
Frame Rates	0.75 - 200 fps (depending on recording format and sensor mode)
Dimensions	185 mm x 125 mm x 140 mm
Power Consumption	Approx. 50 W
Outputs	HD-SDI
Sensor Size	Super 35 format
