ARRI ALEXA Mini User Manual

68 Home screen
1
2
3
4
5
6
3. Upon pressing ADD, an editor opens.
4. Create a value with the jogwheel (1):
°
Scroll up or down to increase/decrease.
°
Press the wheel to select the next digit (2).
°
For the previous digit: Press ARROW (5).
°
To zero the decimals: Press the ZERO button (3).
5. Press ADD TO LIST (4) to save the changes. Cancel with BACK (6).
13.4.2 Deleting an FPS value
1
1. Open the FPS list.
2. Press DELETE (1).

ARRI ALEXA Mini Specifications

General

Sensor Type	ALEV III CMOS
Dynamic Range	14+ stops
Recording Formats	ARRIRAW, ProRes
Power Input	10.5-34 V DC
Base Sensitivity	EI 800
Lens Mount	PL mount
Weight	2.3 kg
ISO Range	160 to 3200
Frame Rates	0.75 - 200 fps (depending on recording format and sensor mode)
Dimensions	185 mm x 125 mm x 140 mm
Power Consumption	Approx. 50 W
Outputs	HD-SDI
Sensor Size	Super 35 format
