12 Avaya 374x DECT Telephones - User Guide 02/2016
IPBS1 with External Antennas
The IPBS1 is available with two omni-directional external antennas. Other external antennas
can be mounted as well. This section contains the differences between the IPBS1 with internal
and external antennas. For all other information see IPBS1 with Internal Antenna
on page 10.
Contents of the Box
l The box in which the IPBS1 is packed contains:
l An IPBS1 for external antennas
l Two antennas
l A mounting bracket
l Two screws with wall plugs
Note: The IPBS1 cannot be mounted with the antennas pointing downwards as the mounting bracket
does not support it.
Insert the antennas into the IPBS1 before following the installation instructions in Install the
Base Station on page 35.
IPBS2
The following versions of the IPBS2 are available:
l IPBS2 with internal antenna
l IPBS2 with internal antenna for IP Office
l IPBS2 with external antennas
The IPBS2 is backward compatible with the IPBS1 when it comes to coverage, functionality,
accessories and mounting bracket. If an old IPBS1 has to be replaced you just reuse the
mounting bracket and install the IPBS2.
IPBS2 with Internal Antenna
This description also applies to the IPBS2 with internal antenna for IP Office. The following
versions are available:
l IPBS2-C3A/1A,
l IPBS2-C4A/1A e
l IPBS2-Z3A/1A
