Installation of the Base Station
Avaya 374x DECT Telephones - User Guide 02/2016
41
Pinning
1. Cut the cable to the correct length and connect the cable to a RJ45 modular jack.
2. For information on the pinning of the data jack see the following:
l IPBS, Pin the IPBS Cable on page 42.
l BS3x0 and DB1, Pin the BS3x0/DB1 Cable on page 43.
Tip: Do not plug the connector in the base station yet.
Note: Since the distance between the base station and the wall is limited, a RJ45 modular jack without
cable retention must be used.
