22 Avaya 374x DECT Telephones - User Guide 02/2016
DB1 with Internal Antenna
Figure 6. DB1 Overview
Contents of the Box
The box in which the DB1 is packed contains:
l A DB1 with integrated antennas
l A mounting bracket
l Two screws with wall plugs
Front view
LED
DECT
(RJ45)
Power Supply
(RJ45)
Back view while lying down
Used for cable ties
to provide strain
relief for cables
Back view
DIP switch
1
ON
234
