36 Avaya 374x DECT Telephones - User Guide 02/2016
3. Position the mounting bracket with its flat side to the wall and fasten it with the two
included 3.5 mm screws.
Figure 8. Fixing the mounting bracket to a wall.
Fix the Mounting Bracket to a Ceiling
Fixing to a ceiling is done in the same way as the a wall, see Fix the Mounting Bracket to a
Wall. When the base station has to be positioned above a suspended ceiling, make sure that
the front of the base station points downwards.
Figure 6.
TOP
100 mm (IPBS2)
65 mm (IPBS1)
Ceiling
