20 Avaya 374x DECT Telephones - User Guide 02/2016
DECT Base Station
Figure 5. BS3x0 Overview
Contents of the Box
The box in which the base station is packed contains:
l A base station
l Two antennas (only base station with external antenna)
l A mounting bracket
l Two screws with wall plugs
Power Distribution
The base station can be powered using the following methods:
l From the IPBL via the Express Powering Pair (EPP) and data pairs
l With a local AC-adapter
Note: For more information about power distribution, see Power the Base Station on page 44.
Test
(RJ12)
Data/Power
(RJ45)
Data/Power
(RJ45)
Front viewBack view
LED1
LED2
