Avaya IPBS2 - Secure the Cable

40 Avaya 374x DECT Telephones - User Guide 02/2016
Figure 11. Connect external antennas.
Secure the Cable
For safety reasons secure the base station cable to a convenient point at about 30 cm from the
base station.
If for some reason the base station drops, it is secured by the cable.
TOP
Min 74 mm
Max 250 mm
1
3
coaxial cable
lock nut
antenna
base station
antenna bracket
mounting bracket
2
TOP
