Configuration
Avaya 374x DECT Telephones - User Guide 02/2016
53
Configuration
This section describes how to configure the IPBS and IPBL using the web interface. The
recommended order to configure the equipment in the IP-DECT system is as follows:
1. Configure the Master, see Configure the Master
on page 64.
2. Configure the Standby Master, see Configure the Standby Master
on page 65.
3. Configure the slaves/radios, see Configure the Slave/Radio
on page 66.
Note: When the IPBS/IPBL is reconfigured to another role (for example from being a Standby Master
to becoming a Master), a factory reset should be done. See Reset Using the Reset Button
on page 142.
Requirements
The following is required in order to configure the IP-DECT system:
l PC
l 10/100base-T Ethernet connection
Web Browser Requirements
To use the interface properly, the web browser has to meet the following requirements:
l HTTP 1.1 protocol
l HTML 4.0 protocol
l XML/XSL Version 1.0
The GUI has been tested with Internet Explorer 7.x and Firefox 3.x, but can also be operated
with other browsers in compliance with the requirements above.
Access the GUI
The GUI interface is accessed through a standard web browser. It is possible to use the name,
ipbs-xx-xx-xx (IPBS1), ipbs2-xx-xx-xx (IPBS2) and ipbl-xx-xx-xx (IPBL), where xx-xx-xx is the
end of the MAC address.
Note: The IPBL name is always ipbl-xx-xx-xx regardless if LAN1 (MAC xx-xx-xx-xx-xx) or LAN2
(MAC yy-yy-yy-yy-yy) is used.
