42 Avaya 374x DECT Telephones - User Guide 02/2016
Pin the IPBS Cable
Figure 12. Connector pinning of the LAN/PoE connector, power feed over the spare cable pairs.
Figure 13. Connector pinning of the LAN/PoE connector, power feed over the Rx/Tx data cable
pairs.
Figure 9.
Figure 10.
Tx Tx Rx Pwr Pwr Rx Pwr Pwr
15432678
RJ45 modular jack
Tx/Pwr Tx/Pwr Rx/Pwr Spare Spare Rx/Pwr Spare Spare
15432678
