Interfaces
A4.6 Power supply interface
The power supply is connected via an external power supply.
TAB. 19 PIN ASSIGNMENT: POWER SUPPLY
Socket: KYCO KPJ-S3
Connec-
tion
Signal Electrical characteristics
1 GND Voltage: +12V
Power: max. 15W
2+12V
3not used
1
3
2
