AVT MAGIC Series - A6.4 Connection to Power Supply (1); A6.5 Connection to MAGIC DC7;AC1 (2); Data Connection to Keypad (3)

PAGE 158
Technical Data
A6.4 Connection to power supply (1)
TAB. 21 PIN ASSIGNMENT: TO POWER SUPPLY
A6.5 Connection to MAGIC DC7/AC1 (2)
TAB. 22 PIN ASSIGNEMENT: CONNECTION TO MAGIC DC7/AC1 XIP
A6.6 Data connection to Keypad (3)
TAB. 23 PIN ASSIGNMENT: DATA CONNECTION TO KEYPAD
Connector: 6-pin PS/2 male
Pin Signal Electrical characteristics
1Voltage:5V
Power: max. 1500 mA
2
3GND
4+5V
5
6
Connector: 9-pin SUB-D male
Pin Signal Electrical characteristics
1 Baudrate: 9600 Baud
Parität: keine
2RXD
3TXD
4
5GND
6
7
8
9
Connector: 8-pin MINI-DIN male
Pin Signal Electrical characteristics
1 Baud rate: 9600 Baud
Parity: keine
2RX Data
3GND
4
5+ 5V
6
7
8TX Data
12
5
3
6
4
5
96
1
6
2
3
5
1
8
4
7
