Technical Data
A6 TECHNICAL DATA MAGIC DC7/AC1
KEYPAD
A6.1 Keypad
Matrix: 8 x 6
32 keys (4 quad keys, 4 double keys, 24 single
keys)
A6.2 LCD Display
2 x 20 characters
illuminated
A6.3 Connecting cable
FIG. 95 CONNECTING CABLE MAGIC SYSTEM - KEYPAD
Protocol
9600 Baud
no parity
to MAGIC DC7/AC1 XIP
to power supply
to keypad
(1)
(2)
(3)
