PAGE 72
Windows PC Software
Main Nominal Level
• If you select the analogue mode for input or output, the corresponding
slide controller is displayed to set the nominal Audio level of the XLR Au-
dio interfaces (Main Nominal Level). The main nominal level can be adju-
sted separately for the input (Level In) and for the output (Level Out) wi-
thion a range of -3 ... +9 dBu in steps of 1-dB. The headroom is 6 dB. If you
want to have the maximum level of 15 dBu for the system, you need to set
9 dBu as main nominal level. The default setting is 0 dBu.
Audio Level Offset
• Via the scroll bar Audio Level Offset you can adjust the Audio Output si-
gnal within the range of -16 ... +15 dBu digitally in 1-dB steps. The default
setting is 0 dBu.
NOTE
Changing the Audio Level Offset is only seldom required if e.g. the signal of
the remote side is always much too loud or much too low. Please note that if
the Audio level Offset is increased, the headroom is decreased correspondin-
gly.
