PAGE 80
Windows PC Software
Relay
The following description is valid for both configuration windows Relay 1
(Pin 6+7) and Relay 2 (Pin 8+9).
FIG. 51 RELAY
The functions for programming the relays are identical with the function co-
des for the TTL output. The following options (Function Code) are available:
– Always open:The relay contacts are always open.
– Always closed: The relay contacts are always closed.
All further function codes are explained under TT Pin as Output (Page 78).
ATTENTION Please note the maximum switching current is 200 mA and the maximum
switching voltage is 48V per relay output.
!
