134 BD High Throughput Sampler User’s Guide
Figure 4-18 HTS sheath and waste lines
6 Connect the purging assembly line to the Sheath (B) port.
The purging assembly line is located in the spares kit.
7 Put the end of the purging assembly line into a 500-mL beaker containing
DI water.
8 Put the safety cover on the HTS.
filter
BD HTS sheath line
sheath connector
purging assembly line
beaker of DI water
Sheath (B) connector in port
