Chapter 3: Running Samples 63
Figure 3-4 Installing the sample coupler on the BD LSR II
NOTICE Make sure the sample coupler is securely connected to the SIT.
7 Turn on the HTS.
The power switch is on the right side of the HTS unit. See Figure 3-5.
Figure 3-5 Power switch
sample coupler
tightening nut
gap
SIT protector
power switch
power switch
