66 BD High Throughput Sampler User’s Guide
Figure 3-7 Experiment Inspector
8 Click on the arrow next to the New Plate button ( ) in the Browser
toolbar and select a plate from the drop-down list.
The list contains plates that have been validated with the HTS. For details
on each plate type, see Table 3-1 on page 66.
NOTICE The HTS is compatible only with standard-depth 96- or 384-well
plates.
BD plates can be ordered from BD Discovery Labware. For ordering
information, visit the BD Discovery Labware website at
bdbiosciences.com/discovery_labware/.
Table 3-1 Plates compatible with the BD High Throughput Sampler
Plate Type Well Capacity (µL) BD Catalog No.
384 flat-bottom 120 353233
96 flat-bottom 300 353915
96 U-bottom 300 353910
96 V-bottom 340 353263
Use global cytometer
settings checkbox
