110 - Data Logger
Starting the Data Log
Start the Data Log by tapping on the "Record" button ( ) in the main
configuration window. The button changes to a "Stop" button ( )
allowing you to interrupt you Data Log, when necessary.
Figure 105: Counting down the delay
The actual start of Data Logging depend on general settings as follows:
• If you have defined a delay in the Delayed Start field, an hour glass
with a down counter appears for as long as the delay requires. The
delay may be either a defined wait time, e.g. 5 minutes, or a specific
time of the day, e.g. 5:15 PM.
• If your Logging Method is "Key Press", a camera button appears for
you to take "snap shots" of the measurements.
When the possible delay defined in general settings has expired, possible
triggers defined for individual channels delay the start of the Data Logging.
Any channel that trigs, starts the Data Log.
You may change the view from the main configuration window to the graph
view by tapping on the title bar. The active area is indicated in Figure 106:
Title bar's active area (shown as yellow) for toggling between main view
and graph view.
Figure 106: Title bar's active area (shown as yellow) for toggling
between main view and graph view
