60 - Tools
Tools for Measurements
Figure 48: Tools for measurements (as seen in Temprature
Calibrator)
Tool Description Available in
Scaling Any signal may be scaled
provided the conversion
is known. When scaling is
active, it is indicated with a
triangle in the unit button.
The true measurement value
is shown in the additional
info row at the bottom of the
subwindow.
• Temperature
Calibrator
• Calibrator
• Documenting
Calibrator*
• Data Logger
* Scaled units are not
supported in CMX nor in
LOGiCAL.
Alarm Main measurements may
be assigned with four alarm
limits: high, low, high and
low change rate. Active
alarms are shown above the
main measurement. When
an alarm limit is exceeded,
a warning signal is heard.
A button for acknowledging
an alarm appears when
needed.
• Temperature
Calibrator
• Calibrator
