Tools for Measurements - 61
Tool Description Available in
Leak / Stability
Test
A leak/stability test may
be assigned to main
measurements. It tests the
leak or stability of, e.g. a
pressure measurement
system.
In the Leak / Stability
Test configuration window:
Enter Test time and start
recording. Use the "+30 sec"
button to increase the test
time, when needed.
• Temperature
Calibrator
• Calibrator
• Documenting
Calibrator
• Data Logger
Damping Use damping when a
measurement signal
contains unwanted noise.
Select one of the available
options.
When Damping is used, a
funnel appears to the left
of the main measurement.
When damping is active, the
following symbol is shown
above the unit button:
• Temperature
Calibrator
• Calibrator
• Documenting
Calibrator
• Data Logger
Resolution Any signal's resolution may
be increased or decreased.
Altered resolution is
indicated in sub-window,
e.g. ".-2" equals two less
decimals.
• Temperature
Calibrator
• Calibrator
• Documenting
Calibrator
• Data Logger
To Next Page
