154 - Additional Information
Figure 147: Sensor Calculation Formula options
Note: If you need to enter very small or big number into Factor
field, open the menu available in Soft Numeric Keypad.
When applicable, the menu contains a possibility to insert an
exponent. This allows entering numbers in scientific notation,
e.g. 5.775E-07.
Callendar van Dusen Formula for PRTs
When CvD RTD (R
0
, A, B, C), i.e. Callendar van Dusen formula is
selected, sensor coefficients can be added, see Figure 148: Example of
configuration page for Callendar van Dusen constant and coefficients.
