Get mapped value feature - 99
The selection of which transmitter’s field is copied into which MC6-T field
is configurable.
With this feature, you may add instrument data to MC6-T from Smart
Instruments using Digital Communication:
• HART® instruments,
•
FOUNDATION Fieldbus H1
tm
instruments and
•
PROFIBUS PA
tm
Instruments
All you need is connect the instrument to MC6-T, select a communication
protocol and receive data of the Instrument using Digital Communication to
MC6-T's Instrument Data. No error prone manual entry of Instrument Data.
MC6-T has pre-entered default mappings (which Digital Communication
Instrument field goes to which field in MC6-T) but you may customize the
mapping for each instrument model you use.
Note: Utilizing this feature requires that your MC6-T has the
option to communicate with the smart instrument type (Fieldbus
option) you want to add to MC6-T's instrument data.
You may easily populate CMX's Instrument database by first
mapping instrument data to MC6-T and then transferring the
instruments to CMX.
More of Instrument's utilizing Digital Communication can be found in
chapter Communicator.
Getting and Editing Mapped Data
Preparations
The data mapping can be done to a new instrument or to an existing
instrument in MC6-T. The Instrument's Output has to be one of the
following:
• Current (measurement),
• HART®,
•
FOUNDATION Fieldbus H1
tm
or
•
Profibus PA
tm
.
Note: With Current Measurement as the Instrument's Output,
the communication is available for the HART transmitter found in
address 0 only.
