Replacing the mains fuses - 141
Maintenance
Warning: There are no user-replaceable parts within the
device. Do not open the enclosure!
Warning: Before any maintenance actions, switch off the Mains
switch and disconnect the Mains cord. Detach all other cables as
well.
CAUTION: In case an item is dropped inside the device, the
device must be switched off and Mains cord disconnected
immediately, after which the item must be removed by an
authorized person.
Replacing the mains fuses
In order to replace the mains fuses follow steps below:
Warning: Switch off the device with the Mains switch
and disconnect the Mains cord. The Mains cord must be
disconnected to completely remove Mains Voltage from the
device.
1. Remove the fuse holder caps using a screwdriver (fuse holder caps
have a spring-load mechanism, press the cap gently and turn 30°
counter-clockwise to open).
2. The fuses must be replaced with the correct rating and type
according to the mains voltage region. See the specified rating and
type on the sticker above the fuse holder.
Warning: Using fuses of wrong type may cause a hazard.
3. After replacing the fuses, attach the fuse holder caps to the
equipment.
4. Connect the Mains cord and turn on the Mains switch. If the fuse
blows again, ensure that you used correct type of fuse. If fuse type is
correct and fuse still blows, send the device to the authorized service.
