Calibrating Instruments - 75
Figure 58: Typical calibration procedure
Note: Although MC6-T assists you in doing the calibration,
you need to know how instruments are calibrated; be, e.g.
a calibration technician. MC6-T is a tool for calibration
professionals.
Generating/Simulating the Input Value
How you change the generated/simulated value is explained in chapter
Active Terminals and Connections, subchapter Changing the Generated/
Simulated Value.
Instrument List
When you start the Documenting Calibrator, you arrive in Instrument List
window. See Figure 59: Example of an Instrument List for an example of
an Instrument List.
