Patient Monitor User’s manual
12-2
should appear on the screen of the monitor.
7. Flush the system once with saline water mixed with heparin every 15min,
this will keep the tubing without jam.
Warning:
The pressure measuring side of the transducer should be on the same
level as the heart of the patient in the process of zero-setting and
measurement.
If air bubbles appear in the tubing system, flush the system with the
infusion solution again. Air bubbles may lead to a wrong pressure
reading.
If measuring intracranial pressure with a sitting patient, level the
transducer with the top of the patient’s ear. Incorrect leveling may
give incorrect values.
Caution: The monitoring procedure may be different depending on
the different IBP accessories, please conduct the IBP
measurement as actual status.
3-way stopcock 2
Extension tube
3-way stopcock 1
bag in pressure bag
Artery needle
Pressure sensor
Stopcock
Pressure
Connecting to
IBP connector
To Next Page
