Patient monitor User’s manual
17-3
17.2 Hemodynamic Calculation
17.2.1 Calculation Step
1. Select 【 Main Menu 】 smartkey→ 【 Calculation 】 , then select
【Hemodynamic】.
2. Input each parameter’s value correctly:
a) If you are calculating the current patient, the monitor can get C.O.,
HR, Height and Weight automatically. And you need to put in the
other parameters’ value by yourself.
b) If you are not calculating the current patient, you need to input all of
the parameters’ value by yourself.
3. After you have finished the data input, please make sure they are correct.
Then you can press the button【 Calculation 】 to get all the output
parameters’ value.
4. In the Calculation Step window, you can:
a) Select【Range】, the unit of each parameter disappears, and the unit of
the parameter in red word will be changed into the logical range of
them. The option has been changed into【Unit】, select【Unit】to
redisplay the unit of each parameter.
b) Select【Record】to print the current page out.
c) Select【Show Input】to display the corresponding input value of the
current calculation result.
Note:
If there is a sign of “---” in the output parameter, it means the
parameter is invalid in this calculation.
If the output parameter is red, it means the parameter is beyond the
logical range.
